Endorphin.es Grand Terminal


Dual voltage controlled AD/AR/looping envelope & dual gates, FX processor

In stock



  • 26 HP, 1” in depth – super slim and Shuttle friendly
  • Dual multi-mode filter (ladder, diode, vactrol, state-variable lp/hp/bp and comb) in dual, stereo and serial modes
  • Dual AD/ASR/looping envelope generator that acts as band-limited oscillator when cycling at linear slopes
  • Stereo “Cabin Pressure” processor with different ambient effects: from shimmered halls and reverberations to a spring simulation over tape/ping-pong delays to a chorus
  • Separate mono modular level output and stereo line level output for direct line recording or driving the headphones.
  • Easy firmware update via USB
  • And of course fully compatible with GatewayT_XP
  • I/O: 48 kHz 16 bit audio

110 mA +12V
45 mA -12V
0 mA 5V
26 mm Depth

Additional information

Weight 0.4 kg
Dimensions 25 × 17 × 9 cm
